Powered by Doosan
66KVA--750KVA standby power @50HZ
The original import from Korea.
DOOSAN Group founded in 1896 is one of the largest consortium in Korean currently. Doosan Engine is established after the acquisition of Daewoo Integrated Machinery Co.,Ltd in 2005, named Doosan Engineering Machinery, and continue to develop and launch a new generation product with first class and reliable performance bace on the original Daewoo engine.
| 50Hz | ||||||||||
| Genset Model | Standby Power | Prime Power | Engine Model | Alternator Model | Fuel Consumption | Genset Weight (Kg) | Genset overall LxWxH (MM) | Click for Detail Data | ||
| kW/kVa | kW/kVa | Doosan | Stamford | L/H | Open type | Silent type | Open Type | Silent type | ||
| SQD165 | 132/165 | 120/150 | DP086TA | UCI274F | 34.8 | 1420 | 2430 | 2360x830x1334 | 3200x1133x1766 | |
| SQD220 | 176/220 | 160/200 | DP086LA | UCI274H | 43.1 | 2000 | 2500 | 2795x968x1632 | 3750x1080x2070 | |
| SQD250 | 200/250 | 180/225 | DP086LA | UCDI274J | 46.8 | 2000 | 3380 | 2650x960x1632 | 3600x1333x2040 | |
| SQD275 | 220/275 | 200/250 | P126T I | UCDI274K | 52 | 2000 | 3400 | 2650x960x1632 | 4300x1483x2145 | |
| SQD300 | 240/300 | 216/270 | P126T I | HCI444D | 58.1 | 2800 | 3200 | 3216x1015x1600 | 4810x1350x2260 | |
| SQD330 | 264/330 | 240/300 | P126T I-II | HCI444D | 61 | 2550 | 4450 | 2950x1060x1650 | 4300x1483x2145 | |
| SQD385 | 308/385 | 280/350 | P158LE-1 | HCI444E | 72 | 3120 | 4495 | 3050x1160x1645 | 4300x1483x2145 | |
| SQD415 | 332/415 | 300/375 | DP158LC | HCI444FS | 85 | 3050 | 5327 | 3100x1150x1700 | 4300x1483x2145 | |
| SQD440 | 352/440 | 320/400 | DP158LC | HCI444F | 87 | 3050 | 5360 | 3150x1090x1750 | 4300x1483x2145 | |
| SQD500 | 400/500 | 360/450 | DP158LC | HCI544C | 99.6 | 3000 | 4500 | 3120x1390x1690 | 4650x1800x2220 | |
| SQD550 | 440/550 | 400/500 | DP158LD | HCI544C | 97 | 3720 | 5700 | 3300x1280x1950 | 4800x1683x2200 | |
| SQD575 | 460/575 | 420/525 | DP158LD | HCI544D | 106 | 3720 | 6200 | 3300x1280x1950 | 4800x1683x2200 | |
| SQD605 | 484/605 | 440/550 | DP180LA | HCI544D | 113 | 3860 | 6650 | 3250x1280x1950 | 4800x1683x2200 | |
| SQD625 | 500/625 | 452/565 | DP180LA | HCI544E | 127.7 | 4820 | 6500 | 3700x1570x2080 | 5030x1860x2550 | |
| SQD688 | 550/688 | 500/625 | DP180LB | HCI544FS | 128 | 4400 | 6700 | 3400x1550x2120 | 4800x1683x2200 | |
| SQD738 | 590/738 | 536/670 | DP222LB | HCI544F | 145 | 4650 | 9000 | 3600x1400x2000 | 5000x1983x2371 | |
| SQD813 | 650/813 | 590/738 | DP222LC | LVI634C | 225 | 7950 | 11985 | 3700x1820x2300 | 6058x2438x2896 | |
★Remarks:
1. Above Sanqpower Gensets are based on 50HZ,1500 RPM, 400/230V, PF0.8 3phase 4wires other special voltage can be satisfied.
2. Requirements for Soundproof Canopy, ATS, Synchronizing Parallel Control panels etc are optional.
3. We observe the rights of data’s adjustment without prior notification.
